Converting Legacy Mainframe & Embedded Applications to C, C++, CPP, C#, CS, JAVA, VB, Structured Text (ST), .NET

Software Product Box Image

FEATURES

  • Simple to use, automated process
  • Translation of ASM51 fragments
  • Translation of INCLUDE or COPY files
  • Translation of ASM51 directives
  • Support for card format input
  • Extensive error checking diagnostics
  • Accurate translation
  • Run time interface
  • Easy to install
  • Compatible with many C and ANSI C compilers
  • Translates include files on the fly
  • Moves nested procedures
  • Completes unqualified structure members
  • Flags ASM51 syntax errors in listing file
  • Outputs ANSI C or K&R C
  • Generates C translation files with comments logically placed
  • Includes skeletons in C of runtime support functions
  • Provides a list of implicitly declared variables in each module
  • Has a by-pass capability that allows translation even with syntax errors in the input file
  • Converts ASM51 programs to C so you can move your program to other processors
  • Translation may be done in an editor environment with error message capability using "Brief" or any editor that is supported
  • Flags syntax errors and generates listing file with levels for include files
  • WIN32 protected mode operation allows translation of very large source files (more then to 500,000 lines per file)
  • KEYWORDS

    ASM, ASSEMBLY,ASM51, ASM8086, ASM186, ASM286, ASM386, ASM486, Intel, ASSEMBLER, ASSEMBLER

    REFERENCES

    ASM51 Macro Assembler Operating Instruction by Intel
    8051 Cross Assembler User's Manual By MetaLink

    LINKS

    Why Convert from ASM to C?

    Micro Controller FAQ

    Disassembling FAQ

    CONTACT

    Micro-Processor Services, Inc.
    Tel. 631 499 4461
    Fax. 631 499 4727
    Contact us

    ASM51C
    Intel ASM 51 to "C" Translator, Converter:
    Reverse Engineering For Assembly Source Code


    The ASM51C® translator is a Microsoft Windows program that translates Intel ASM51 programs to "C". The translation process is a turn key process with minimal user intervention. The translator output is ANSI C or K&R C code that is ready to be tested with the target compiler. Simply run your ASM51 code through the translator and start debugging C code with your target compiler.

    GENERAL DESCRIPTION

    The ASM51C® translator is a software tool that will convert existing ASM51 programs to "C". The powerful ASM51C® translator acceptsASM51 programs, checks their syntax and outputs C code. The comments are moved transparently from the source file to the target file. Any built-in functions for math, string manipulation and I/O in ASM51 are converted to calls to external procedures (Get free sample translation) .

    The ASM51C® translator contains a syntax analyzer, an ASM51 to tertiary converter, and a tertiary to "C converter. The syntax analyzer scans the ASM51 input file for syntactic errors and generates a listing file of the ASM51 program. Any syntactic errors will be flagged with detailed English messages in the listing file. If no errors are encountered, the ASM51 input file is converted to tertiary language. Then the tertiary file is checked and, if no errors are detected, it is converted to "C". A command line control is provided to allow translation with errors in the source file. This is helpful when translating code fragments that are not complete programs.

    The translation of the ASM51 source language into an intermediate tertiary language ensures the logical equivalence between the source and target languages. This sophisticated tertiary language, which is common to our entire family of translators, allows complex mapping from source language to the target. The tertiary language is automatically converted to "C" while maintaining the logical equivalence between the output "C" program and the input ASM51 program.

    The "C" output file will be generated in

    1. Compact and portable K&R C
    2. Standard ANSI C code

    as selected by a command line option.

    ASM51 OPERATORS:

    AND EQ GE GT HIGH LE LOW LT MOD NE NOT OR SHL SHR XOR

    ASM51 OPCODES:

    ACALL ADD ADDC AJMP ANL CJNE CLR CPL DEC DIV DJNZ INC JB JBC JC JMP JNB JNC JNZ JZ LCALL LJMP MOV MOVC MOVX MUL NOP ORL POP PUSH RET RETI RL RLC RR RRC SETB SJMP SUBB SWAP XCH XCHD XRL

    ASM51 DIRECTIVES:

    BIT BDSEG CODE CSEG DATA DB DBIT DS DSET DW END EQU EXTRN IDATA ISEG NAME ORG PUBLIC RSEG SEGMENT SET USING XDATA XSEG

    REGISTERS: A AB B C DPH DPL DPTR PSW PC SP

    ASM51 Variants Currently Supported:

    DS5000,DS80C320
    80C152JA/JB/JC/JD, 83C152JA/JC, 80C157
    80C154, 83C154, 85C154
    8044, 8344, 8744
    80C451, 83C451, 87C451
    80C452, 83C452, 87C452
    8051, 8031, 8751, 80C51, 80C31, 87C51
    80512, 80532
    80515, 80535, 80C535, 80C515
    80C517, 80C537
    80C51FA, 83C51FA, 87C51FA, 83C51FB, 87C51FB, 83C51FC, 87C51FC
    8052, 8032, 8752
    80C321, 80C521, 87C521, 80C541, 87C541
    8053, 9761, 8753
    80410,80451,80452
    80515,80517
    80C552, 83C552, 87C552
    80C652, 83C652, 87C652
    83C654, 87C654
    83C751, 87C751
    83C752, 87C752
    80575,80576,
    80C851, 83C851

    TECHNICAL INFORMATION

    CPU SUPPORTED:

    HOSTS SUPPORTED: The translators run under all Microsoft Windows platforms. Porting of the translator to other hosts is available.

    TRANSLATION METHOD: Double conversion from ASM51 to tertiary and then from tertiary to "C".

    TRANSLATION CAPACITY: WIN16 version can translate up to 40,000 lines per file. WIN32 version can translate more then 500,000 lines per file.

    TRANSLATOR RUN TIME SUPPORT: Skeletons in "C" of the run time support function are available with the translator.

    SOFTWARE FORMAT AND MEDIA: CD for Windows or floppy for MS-DOS version.

    DOCUMENTATION: User's Guide

    COPY PROTECTION: Includes a special security lock

    SUPPORT: Includes 30 days free telephone or e-mail technical support. For updates, monthly support must be purchased.

    WEIGHT: 2 pounds

    ORDER: ASM51C
